Titanium 12 Point Flange Bolt, M12 x 1.75 x 60 mm, 20 mm Thread | AVID Racing
Description
Description
Titanium 12 Point Flange Bolt, M12 x 1.75 x 60 mm, 20 mm Thread | AVID Racing
The Titanium 12 Point Flange Bolt, M12 x 1.75 x 60 mm, 20 mm Thread is an AVID titanium bolt for applications that require a coarse-thread M12 fastener with a 12 point flange head.
Specific Bolt Specs
- SKU: AVID-THWB-M12Cx60x20
- Hardware type: 12 point flange bolt
- Thread size: M12 x 1.75
- Total length: 60 mm
- Thread length: 20 mm
- Shank length: 40 mm
- Material: Ti-6Al-4V titanium
Why Upgrade to AVID Titanium Hardware?
AVID titanium hardware is precision made from lightweight, corrosion resistant Ti-6Al-4V titanium for off-road, race, and fabrication use.
Use this bolt when the listed M12 x 1.75 thread pitch, 60 mm total length, 20 mm thread length, and 40 mm shank length match the required hardware stack.
Apply anti seize on the shank where applicable and blue lock tite on the threads where applicable. Torque M12 AVID titanium hardware to 83 Nm / 61 ft-lb as a reference only, and always verify the manufacturer-required torque specification before installation because clamping force is application specific.
Titanium 12 Point Flange Bolt, M12 x 1.75 x 60 mm, 20 mm Thread | AVID Racing may have a manufacturing lead time. Contact sales for exact ship date.
