Back to titanium hardwareTitanium 12-Point Flange Bolt, M14 x 2.0 x 95 mm, 22.5 mm Thread Length
Purchase options
Choose the exact part
Currently unavailable
Final fulfillment timing is confirmed after checkout. Contact AVID before ordering if you have a firm deadline.
AVID must confirm a valid selling price before this variant can be added to cart. Contact us for current pricing and availability.
Request pricing reviewThe complete vehicle application has not yet been published for this item.
Ask AVID about fitmentAVID Ti exact-data reference
Individual hardware specifications
Match the measurement system, thread, every listed dimension, head, drive, grade, and piece count.
- Titanium family
- Hardware
- Component type
- Bolt
- Measurement system
- METRIC
- Thread designation
- M14x2.0
- Nominal diameter
- 14 mm
- Thread pitch
- 2 mm
- Overall length
- 95 mm
- Thread length
- 22.5 mm
- Shank length
- 72.5 mm
- Head style
- Twelve point flange
- Drive style
- 12 point
- Material grade
- Titanium
- Pieces per product
- 1
- Pack quantity
- 1
- Unit of sale
- Each
- Anodizing eligibility
- Not eligible
- Specification status
- Verified
Product information
Details when you need them.
Review the product description, exact dimensions, documents, and technical support.
Overview and included items
Titanium Hardware M14-T12FB-95x725-20 | AVID Racing
The Titanium 12-Point Flange Bolt, M14 x 2.0 x 95 mm, 22.5 mm Thread Length is a single AVID titanium fastener with a 12-point flange head, M14 x 2.0 thread, 95 mm total length, and 22.5 mm thread length.
Specific Hardware Specs
- SKU: AVID-THWB-M14x95x225
- Hardware Type: 12-Point Flange Bolt
- Thread Size: M14 x 2.0
- Total Length: 95 mm
- Thread Length: 22.5 mm
- Material: Titanium
Why Upgrade to AVID Titanium Hardware?
Precision-made titanium provides a lightweight, corrosion-resistant hardware option for off-road, race, and fabrication use.
Application fitment depends on the complete hardware stack and mounting requirements.
Use anti seize where the shank passes through pivot locations and blue lock tite on the threads when applicable. The M14 reference torque is 132 Nm / 97 ft-lb; final torque must follow the manufacturer-required, application-specific specification.
Installation Notes
Apply anti seize where service removal is required or blue lock tite where the assembly manufacturer calls for medium-strength thread retention; do not use both on the same interface. Verify the complete hardware stack and manufacturer-required torque specification before installation because clamping force is application specific.
