30.2 mm Weld Spacing Slug, 14 mm Bore, 6061 Aluminum

AVID Racing Weld Spacer SKU AVID-WLDSPC-302

Purchase options

Choose the exact part

Specifications

Final fulfillment timing is confirmed after checkout. Contact AVID before ordering if you have a firm deadline.

Match every listed specification. Verify dimensions, material, intended use, and mating components before purchase.
$8.60

Available to order

Total $8.60 Current selection

Match every listed specification and complete each required selection before adding this part to your cart.

Planning this vehicle build? Save this exact variant to a vehicle in My AVID Garage and track its public price over time.
This records product interest only. It does not reserve inventory, place an order, or begin a payment plan.
My AVID Garage

Save to Planned Build

30.2 mm Weld Spacing Slug, 14 mm Bore, 6061 Aluminum | AVID Racing

Loading your Garage…
Contact AVID Support about this product

Technical reference

Core specifications

Use these values to match the part to the assembly.

Component type
Welding Slug
Material
6061 Aluminum
Width
30.2 mm; 1.189 in
Outside diameter
1.25 in; 31.75 mm
Inside diameter
14 mm; 0.5512 in
Contact AVID Support before ordering if any value is unclear

Product information

Details when you need them.

Review the product description, exact dimensions, documents, and technical support.

Overview and included items

30.2 mm Weld Spacing Slug, 14 mm Bore, 6061 Aluminum | AVID Racing

Our 30.2 mm weld spacing slug holds tabs and brackets apart during welding. Use it for shock mounts and other fabricated assemblies that require this setup spacing.

Machined from 6061 aluminum, it has a 1.25" outside diameter and a 14 mm nominal through-bore. The bore is machined to 14.05 mm ±0.08 mm.

Key Specs

  • Part Number: AVID-WLDSPC-302
  • Component Type: Welding Slug
  • Inside Diameter: 14 mm; 0.5531" ±0.0030" (14.05 ±0.08 mm)
  • Outside Diameter: 1-1/4"; 1.2500" ±0.0030" (31.75 ±0.08 mm)
  • Width / Thickness: 30.2 mm; 30.15 to 30.20 mm
  • Material: 6061 Aluminum
  • Included: Single welding slug

Fitment Notes

Verify the required setup spacing, outside diameter, and through-bore before ordering or welding. Final fitment depends on your tabs or brackets, fixture, and mating hardware.
