Kit Includes

• 16 x AVID-MS33 - Inner pivot misalignments
• 8 x AVID-MS32 - Outer pivot misalignments
• 4 x AVID-MS25 - Lower shock misalignments
• 2 x AVID-WPB16T - LCA outer pivot bearings
• 2 x AVID-UBSR16 - LCA outer pivot snap rings
• 6 x AVID-WPB14T - Inner pivot bearings
• 6 x AVID-UBSR14 - Inner pivot snap rings
• 2 x AVID-JMX14T - Inner pivot rod ends
• 2 x AVID-JNR14S - Inner pivot jam nuts
• 2 x AVID-JMXR16T - UCA outer pivot rod ends
• 2 x AVID-JNR16S - UCA outer pivot jam nuts

This AVID Racing complete service kit is built for servicing the AVID Baja Race front control arm kit on the Can-Am Maverick R. It includes the confirmed replacement misalignments, bearings, snap rings, rod ends, and jam nuts needed to refresh the front control arm pivot and shock mounting locations in the matching AVID setup.

This is a service kit for an existing AVID front control arm kit. It is intended for replacing worn, damaged, or service-life components from the matching AVID Baja Race front control arm assembly. This listing is not a complete front control arm kit.

Service Kit Application

This kit is organized for the Baja Race front control arm pivot locations, including inner pivots, outer pivots, lower shock misalignments, LCA outer pivot bearings, and UCA outer pivot bearings. Use this kit when refreshing the service components in the matching AVID Can-Am Maverick R Baja Race front control arm setup.

Installation Notes

Inspect the control arms, pivot bores, hardware, and bearing seats before installation. Replace any damaged hardware or structural components separately as needed. Bearings, snap rings, rod ends, jam nuts, and misalignments should be installed by a qualified technician using the correct tools, proper retaining clip seating, and the manufacturer-required torque specifications for the complete assembly.

Verify the kit, machine application, pivot locations, and component quantities before installation.
