JMX08T 3-Piece Chromoly Rod End - 1/2-20 RH Thread

AVID Racing Rod End SKU AVID-JMX08T

Purchase options

Choose the replacement part

Service part
$0.00

Currently unavailable

Match every listed specification. Verify dimensions, material, intended use, and mating components before purchase.
Total $0.00 Current selection

Match every listed specification and complete each required selection before adding this part to your cart.

Planning this vehicle build? Save this exact variant to a vehicle in My AVID Garage and track its public price over time.
This records product interest only. It does not reserve inventory, place an order, or begin a payment plan.
My AVID Garage

Save to Planned Build

JMX08T 3-Piece Chromoly Rod End - 1/2-20 RH Thread | AVID Racing

Loading your Garage…
Contact AVID Support about this product

Replacement reference

Core specifications

Compare these values with the removed part and its mating components.

Material
Chromoly Steel
Thread
1/2-20
Inner diameter
1/2"
Outer diameter
1.312 in
Width
0.625 in
Thread length
1.500 in
Thread hand
Right-hand
Contact AVID Support before ordering if any value is unclear

Product information

Details when you need them.

Review replacement notes, specifications, documents, and service support.

Overview and included items

JMX08T 3-Piece Chromoly Rod End - 1/2-20 RH Thread | AVID Racing

JMX08T gives you a serviceable 3-piece rod end for adjustable suspension and fabrication assemblies that need a 1/2-20 right-hand thread.

Its chromoly construction supports demanding off-road and motorsports use. This listing includes one rod end; jam nut, spacers, tabs, and mounting hardware are not included.

Key Specs

  • Part Number: JMX08T
  • Product Type: 3-piece chromoly rod end / heim
  • Thread: 1/2-20 right-hand
  • Bearing ID / Bore: 1/2" (0.500 in)
  • Head Diameter: 1.312 in
  • Outer Width: 0.625 in
  • Ball Width: 0.500 in
  • Ball Diameter: 0.937 in
  • Centerline Length: 2.438 in
  • Thread Length: 1.500 in
  • Misalignment Angle: 12 degrees
  • Static Radial Load Rating: 16,242 lb
  • Included: One rod end
  • Approx. Weight: 0.25 lb

Fitment Notes

Verify the 1/2-20 thread hand, bore, head diameter, installed width, spacer stack, and mounting hardware before ordering.
