AIN12T-F1 Heavy Duty Precision Uniball, 3/4" ID x 1-1/2" OD

AVID Racing Uniball SKU AVID-AIN12T-F1

Purchase options

Choose the replacement part

Service part
$22.00

Currently unavailable

Match every listed specification. Verify dimensions, material, intended use, and mating components before purchase.
Total $22.00 Current selection

Match every listed specification and complete each required selection before adding this part to your cart.

Planning this vehicle build? Save this exact variant to a vehicle in My AVID Garage and track its public price over time.
This records product interest only. It does not reserve inventory, place an order, or begin a payment plan.
My AVID Garage

Save to Planned Build

AIN12T-F1 Heavy Duty Precision Uniball, 3/4" ID x 1-1/2" OD | AVID Racing

Loading your Garage…
Contact AVID Support about this product

Replacement reference

Core specifications

Compare these values with the removed part and its mating components.

Material
52100 Steel and Alloy Steel
Inner diameter
3/4"
Outer diameter
1-1/2"
Width
0.875 in
Finish
heat-treated, hard-chrome-plated ball; heat-treated, oil-coated race
Contact AVID Support before ordering if any value is unclear

Product information

Details when you need them.

Review replacement notes, specifications, documents, and service support.

Overview and included items

AIN12T-F1 Heavy Duty Precision Uniball, 3/4" ID x 1-1/2" OD | AVID Racing

AIN12T-F1 is a heavy duty precision uniball / spherical bearing with a 3/4" inner diameter and 1-1/2" outer diameter.

The supplied AIN chart identifies a 52100-steel ball and alloy-steel race; this draft does not claim a liner because the chart states that PTFE liners are available without tying that option to the exact AVID suffix. This listing includes one bearing; cups, retaining rings, misalignment spacers, and mounting hardware are not included.

Key Specs

  • Part Number: AIN12T-F1
  • Product Type: heavy duty precision uniball / spherical bearing
  • Bearing ID / Bore: 3/4" (0.75 in)
  • Bearing OD / Head Diameter: 1-1/2" (1.5 in)
  • Bearing Width / Ball Width: 0.875 in
  • Ball Diameter / Ball Radius Reference: 1.312 in ball diameter
  • Misalignment Angle: 10 degrees
  • Static Radial Load Rating: 48,675 lb
  • Material: 52100 steel ball; alloy-steel race
  • Finish: heat-treated, hard-chrome-plated ball; heat-treated, oil-coated race
  • Style: heavy duty precision spherical bearing
  • Included: One uniball bearing
  • Approx. Weight: 0.252 lb

Fitment Notes

Verify bearing ID, OD, width, cup or housing size, spacer stack, and installed width before ordering. Final fitment depends on the housing, spacers, and application-specific hardware.
