Back to Universal & ServiceAIN08T-F1 Heavy Duty Precision Uniball, 1/2" ID x 1-3/32" OD
Purchase options
Choose the replacement part
Currently unavailable
Final fulfillment timing is confirmed after checkout. Contact AVID before ordering if you have a firm deadline.
AVID must confirm a valid selling price before this variant can be added to cart. Contact us for current pricing and availability.
Request pricing reviewThe complete vehicle application has not yet been published for this item.
Contact AVID Support about fitmentReplacement reference
Core specifications
Compare these values with the removed part and its mating components.
- Material
- 52100 Steel and Alloy Steel
- Inner diameter
- 1/2"
- Outer diameter
- 1-3/32"
- Width
- 0.625 in
- Finish
- heat-treated, hard-chrome-plated ball; heat-treated, oil-coated race
Product information
Details when you need them.
Review replacement notes, specifications, documents, and service support.
Overview and included items
AIN08T-F1 Heavy Duty Precision Uniball, 1/2" ID x 1-3/32" OD | AVID Racing
AIN08T-F1 is a heavy duty precision uniball / spherical bearing with a 1/2" inner diameter and 1-3/32" outer diameter.
The supplied AIN chart identifies a 52100-steel ball and alloy-steel race; this draft does not claim a liner because the chart states that PTFE liners are available without tying that option to the exact AVID suffix. This listing includes one bearing; cups, retaining rings, misalignment spacers, and mounting hardware are not included.
Key Specs
- Part Number: AIN08T-F1
- Product Type: heavy duty precision uniball / spherical bearing
- Bearing ID / Bore: 1/2" (0.5 in)
- Bearing OD / Head Diameter: 1-3/32" (1.0937 in)
- Bearing Width / Ball Width: 0.625 in
- Ball Diameter / Ball Radius Reference: 0.937 in ball diameter
- Misalignment Angle: 9.5 degrees
- Static Radial Load Rating: 28,110 lb
- Material: 52100 steel ball; alloy-steel race
- Finish: heat-treated, hard-chrome-plated ball; heat-treated, oil-coated race
- Style: heavy duty precision spherical bearing
- Included: One uniball bearing
- Approx. Weight: 0.11 lb
Fitment Notes
Verify bearing ID, OD, width, cup or housing size, spacer stack, and installed width before ordering. Final fitment depends on the housing, spacers, and application-specific hardware.
