ADS Mesa 2.5" Coilovers - Front 100ADS-10116

ADS ADS Shocks SKU 100ADS-10116

Purchase options

Choose your options and quantity

Vehicle upgrade

Final fulfillment timing is confirmed after checkout. Contact AVID before ordering if you have a firm deadline.

Confirm the complete shock package. Match the application, dimensions, mounts, clearance, position, quantity, and every listed condition.
$1,662.45

Available to order

Total $1,662.45 Current selection

Complete every required choice. AVID verifies the exact components, pricing, and configuration before the system can enter the cart.

Planning this vehicle build? Save this exact variant to a vehicle in My AVID Garage and track its public price over time.
This records product interest only. It does not reserve inventory, place an order, or begin a payment plan.
My AVID Garage

Save to Planned Build

ADS Mesa 2.5" Coilovers - Front 100ADS-10116

Loading your Garage…
Contact AVID Support about this product

Product information

Details when you need them.

Review fitment, performance context, specifications, installation information, and support.

Overview and included items

ADS Mesa 2.5" Coilovers - Front 100ADS-10116

The ADS Mesa 2.5" Coilovers - Front 100ADS-10116 is an ADS factory-replacement shock identified by manufacturer part number 100ADS-10116. 2.5" Mesa IFP Shock, 2007-21', Tundra 0.0" - 2.0" Lift.

What This Means on the Vehicle

  • Product identity: The ADS part number is preserved as 100ADS-10116.
  • Application: 2007-2021 Tundra.

Vehicle Fitment

  • 2007-2021 Tundra

Key Features

  • Product type: Coilover

Specifications

  • Body Diameter: 2.5
  • Collapsed Length: 18.8
  • Cylinder Diameter: 2.5
  • Extended Length: 24.85
  • Mounting Hardware Included: Yes
  • Lower Mount Type: Eyelet
  • Shaft Material: Hard-chrome plated steel
  • Shaft Diameter: 0.875
  • Travel Length: 6.05
  • Stroke: 6.05
  • Strut Mount Insulator(S) Included: No
  • Upper Mount Type: Mounting Plate
Applications and Fitment
Application 1
2000-2013 Toyota Tundra Base
Notes
Provides 0-2 (in) Front Lift
Application 2
2000-2026 Toyota Tundra Limited
Notes
Provides 0-2 (in) Front Lift
Application 3
2000-2011 Toyota Tundra SR5
Notes
Provides 0-2 (in) Front Lift
Application 4
2013-2026 Toyota Tundra Platinum
Notes
Provides 0-2 (in) Front Lift
Application 5
2014-2026 Toyota Tundra 1794 Edition
Notes
Provides 0-2 (in) Front Lift
Application 6
2014-2021 Toyota Tundra SR
Notes
Provides 0-2 (in) Front Lift
Application 7
2014-2026 Toyota Tundra SR5
Notes
Provides 0-2 (in) Front Lift
Application 8
2015-2017 Toyota Tundra TRD Pro
Notes
Provides 0-2 (in) Front Lift
Application 9
2019-2026 Toyota Tundra TRD Pro
Notes
Provides 0-2 (in) Front Lift
Application 10
2021 Toyota Tundra Nightshade
Notes
Provides 0-2 (in) Front Lift
Application 11
2021 Toyota Tundra Trail
Notes
Provides 0-2 (in) Front Lift
Specifications

No additional specifications are currently available for this product.

Downloads and instructions
Installation and Requirements

Confirm every vehicle or dimensional condition, mount, position, clearance, and quantity. Fitment type: Verified direct fit. Provides 0-2 (in) Front Lift
