AVID racing titanium fastener hardware showing precision bolt and nut, updated product imagery coming soon [AVID:d3648568-4c5d-462c-81a3-ffff3c9e9305] [AVID-VERSION:df5cc39a-f22d-4169-92f9-805d50371bab]

Titanium hardware reference

Back to titanium hardware

Titanium 82 Degree Countersink Flat Head Bolt, 3/8-24 x 1 inch, T40 Torx

AVID-TI Titanium SKU 38-TCSFH-100X0-24

Purchase options

Choose the exact part

Specifications

Final fulfillment timing is confirmed after checkout. Contact AVID before ordering if you have a firm deadline.

Match every listed specification. Verify dimensions, material, intended use, and mating components before purchase.
Titanium finish

Raw Ti selected. No anodizing charge.

$3.75

Available to order

Total $3.75 Current selection

Match every listed specification and complete each required selection before adding this part to your cart.

Planning this vehicle build? Save this exact variant to a vehicle in My AVID Garage and track its public price over time.
This records product interest only. It does not reserve inventory, place an order, or begin a payment plan.
My AVID Garage

Save to Planned Build

Titanium 82 Degree Countersink Flat Head Bolt, 3/8-24 x 1 inch, T40 Torx | AVID Racing

Loading your Garage…
Contact AVID Support about this product

AVID Ti exact-data reference

Individual hardware specifications

Match the measurement system, thread, every listed dimension, head, drive, grade, and piece count.

Specification status
Complete dimensions are not yet available. Contact AVID before using this product as an exact dimensional match.
Titanium family
Hardware
Component type
Bolt
Measurement system
SAE
Thread designation
3/8-24
Nominal diameter
0.375 in
Threads per inch
24 TPI
Overall length
1 in
Thread length
0.766 in
Shank length
0 in
Head style
Flat head
Drive style
Torx
Head diameter
0.781 in
Head height
0.234 in
Thread direction
Right hand
Material
Titanium
Pieces per product
1
Pack quantity
1
Unit of sale
Each
Contact AVID Support before ordering if any value is unclear

Product information

Details when you need them.

Review the product description, exact dimensions, documents, and technical support.

Overview and included items

Our Grade 5 titanium countersunk flat head bolt uses a 3/8-24 right-hand thread and a T40 Torx drive. The 1-inch overall length includes the 82-degree countersunk head.

Specifications

  • Material: Ti-6Al-4V Grade 5 titanium
  • Finish: Machined
  • Thread: 3/8-24, right hand
  • Overall length: 1 inch, including head
  • Smooth shank: 0 inches
  • Head: 82-degree countersunk flat head
  • Head diameter: 0.781 inches maximum
  • Head height: 0.234 inches
  • Drive: T40 Torx

Includes

One bolt. Sold individually.
