Titanium hardware reference
Back to titanium hardwareTitanium 12 Point Flange Bolt, 1/2-13 x 3.00 inch, .5 inch Thread
Purchase options
Choose the exact part
Final fulfillment timing is confirmed after checkout. Contact AVID before ordering if you have a firm deadline.
AVID Ti exact-data reference
Individual hardware specifications
Match the measurement system, thread, every listed dimension, head, drive, grade, and piece count.
- Titanium family
- Hardware
- Component type
- Bolt
- Measurement system
- SAE
- Thread designation
- 1/2-13
- Nominal diameter
- 0.5 in
- Threads per inch
- 13 TPI
- Overall length
- 3 in
- Thread length
- 0.5 in
- Shank length
- 2.5 in
- Head style
- Flange head
- Drive style
- 12 point
- Head diameter
- 0.85 in
- Head height
- 0.45 in
- Material grade
- Titanium
- Pieces per product
- 1
- Pack quantity
- 1
- Unit of sale
- Each
- Anodizing eligibility
- Not eligible
- Specification status
- Verified
Product information
Details when you need them.
Review the product description, exact dimensions, documents, and technical support.
Overview and included items
Titanium 12-Point Flange Bolt, 1/2-13 x 3.00 inch | AVID Racing
This titanium 12 point flange bolt is a single AVID titanium hardware item with a 1/2-13 thread, 3.00 inch total length, and .5 inch thread length.
Specific Bolt Specs
- Hardware type: 12 point flange bolt
- Thread size: 1/2-13
- Total length: 3.00 inch
- Thread length: .5 inch
- Shank length: 2.50 inch
- Material: Titanium
Why Upgrade to AVID Titanium Hardware?
AVID titanium hardware is precision-made from lightweight, corrosion-resistant titanium for off-road, race, and fabrication use.
Use this bolt where the confirmed 1/2-13 thread, 3.00 inch length, and 12 point flange bolt style match the required hardware stack.
Use anti seize or blue lock tite as appropriate for the application. 1/2-13 titanium hardware has a reference torque of 439 in-lb / 37 ft-lb, but the installer must verify the manufacturer-required torque specification before installation because clamping force is application specific.
Downloads and instructions
Installation and Requirements
Match every listed dimension, interface, material, and mating component before ordering.
