In fabricated suspension systems, most builders focus on tubing size, weld quality, and material choice. Those things matter — but there’s a smaller component that often gets overlooked and quietly causes long-term problems:

The washer.

In a suspension mount, washers are not cosmetic hardware. They are a functional part of the load path, clamping system, and long-term durability of the joint. When washers are wrong — or missing — even the best fabrication work can fail prematurely.

What a Washer Actually Does in a Suspension Mount

In a properly designed suspension joint, the bolt’s job is to create clamping force, not to carry load in shear by itself. The washer plays a critical role in that system.

A correctly selected washer:

• Distributes clamp load evenly across the tab or bracket
• Prevents localized deformation of softer materials
• Maintains consistent clamping force under vibration
• Protects tabs from fretting and elongation
• Preserves bolt preload over time

Without the right washer, clamping force becomes inconsistent — and that’s where problems begin.

Load Paths: Why Washers Protect Fabricated Tabs

Fabricated suspension tabs often use:

• Mild steel
• Chromoly plate
• Aluminum uprights or brackets

Each material reacts differently under clamp load. When a bolt head or nut bears directly on the tab without a washer, the contact area is small. That concentrates stress in one spot.

Over time, this leads to:

• Ovaled bolt holes
• Cracked tabs
• Loss of torque
• Increased movement in the joint

A washer increases the bearing surface area, spreading load across the tab and allowing the bolt to maintain proper preload.

This is especially important in:

• Long-travel suspension
• Trailing arms
• Radius rod mounts
• Shock mounts
• High-cycle desert and dune use

Washer Thickness Matters More Than People Think

Not all washers are created equal.

Thin, hardware-store washers tend to:

• Dish under load
• Deform during torque
• Lose clamp force after heat cycles

In suspension applications, washers must resist bending and compression. Proper washer thickness helps maintain:

• Flat contact surfaces
• Stable torque values
• Long-term joint integrity

This is why AVID treats washers as engineered components, not generic add-ons.

Washer OD, ID, and Fitment

Correct washer selection isn’t just about thickness — it’s also about geometry.

Important considerations:

• Outer diameter (OD): Must fully cover the tab face without overhanging
• Inner diameter (ID): Should closely match bolt shank size to prevent shifting
• Flatness: Critical for even clamp load
• Material compatibility: Especially important with aluminum components

Poorly sized washers allow movement, uneven loading, and accelerated wear — even if torque specs are followed.

Why Fabricated Suspension Mounts Are Especially Sensitive

Unlike OEM cast components, fabricated mounts rely on:

• Flat plate interfaces
• Welded assemblies
• Precise alignment during installation

Any deformation at the washer interface changes alignment, preload, and load distribution. That can cause:

• Bushing bind
• Premature bearing wear
• Cracked welds adjacent to the tab
• Increased bolt fatigue

The washer is the interface between your hardware and your fabrication — it directly affects how the entire joint behaves.

Race-Proven Engineering Benefits Everyone

While these principles come from race and high-abuse environments, they matter just as much for:

• Weekend riders
• Recreational dune users
• Trail and desert builds
• Long-term ownership

Race-proven washer selection isn’t about chasing performance — it’s about durability, safety, and consistency, no matter how the vehicle is used.

How AVID Approaches Washer Selection

AVID designs suspension systems and hardware packages as complete assemblies. That means:

• Washers are matched to bolt diameter and shank length
• Thickness is selected to resist deformation
• Materials are chosen to work with the surrounding components
• Load paths are considered from bolt head to nut

That’s why all AVID suspension kits include precision-matched washers, not generic hardware.

Because the smallest components often determine how long everything else lasts.

FREQUENTLY ASKED QUESTIONS (FAQ)

Do washers actually matter in suspension mounts?

Yes. Washers are a functional part of the clamping system. They distribute load, protect fabricated tabs from deformation, and help maintain proper bolt preload over time.

Can I run suspension bolts without washers if everything is tight?

No. Even if torque is correct initially, running without washers concentrates load at the bolt head or nut, which can lead to ovaled holes, cracked tabs, and loss of clamping force after heat cycles.

Are thicker washers always better for suspension use?

Not always — but washers must be thick enough to resist dishing and deformation under clamp load. Proper thickness, flatness, and material choice are all critical in suspension applications.

Does washer selection matter for recreational riding, not just racing?

Absolutely. Race-proven washer selection improves durability, safety, and service life for recreational, dune, trail, and desert builds — not just competition vehicles.

Should washer material match the suspension component material?

Material compatibility matters, especially with aluminum components. Proper washer material helps prevent galling, uneven wear, and loss of preload over time.

Why do AVID suspension kits include specific washers instead of generic ones?

AVID designs hardware as part of the suspension system. Washers are selected based on bolt diameter, shank length, material, and load path — not convenience or cost.

Final Thoughts

A washer may seem insignificant compared to tubing, welds, or billet parts — but in a fabricated suspension mount, it’s a structural element.

When washers are selected correctly:

• Clamping force stays consistent
• Tabs stay round
• Bolts stay torqued
• Suspension geometry stays where it belongs

It’s a small detail — but it’s one that separates engineered suspension systems from generic assemblies.
