Shock Mount Cup Weld Spacing Slug, 2.25" Long

AVID Racing Weld Spacer SKU AVID-WLDSPC-SMC1

Purchase options

Choose the exact part

Specifications

Final fulfillment timing is confirmed after checkout. Contact AVID before ordering if you have a firm deadline.

Match every listed specification. Verify dimensions, material, intended use, and mating components before purchase.
$13.00

Available to order

Total $13.00 Current selection

Match every listed specification and complete each required selection before adding this part to your cart.

Planning this vehicle build? Save this exact variant to a vehicle in My AVID Garage and track its public price over time.
This records product interest only. It does not reserve inventory, place an order, or begin a payment plan.
My AVID Garage

Save to Planned Build

Shock Mount Cup Weld Spacing Slug, 2.25" Long | AVID Racing

Loading your Garage…
Contact AVID Support about this product

Technical reference

Core specifications

Use these values to match the part to the assembly.

Component type
Welding Slug
Material
6061 Aluminum
Width
2.25 in; 57.15 mm
Outside diameter
1.355 in; 34.417 mm
Inside diameter
12 mm; 0.4724 in
Contact AVID Support before ordering if any value is unclear

Product information

Details when you need them.

Review the product description, exact dimensions, documents, and technical support.

Overview and included items

Shock Mount Cup Weld Spacing Slug, 2.25" Long | AVID Racing

Our shock mount cup weld spacing slug helps hold the required space during shock mount cup fabrication. It measures 2.25" long with a 1.355" outside diameter.

Machined from 6061 aluminum, the slug has a 12 mm nominal through-bore. Use its length, outside diameter, and bore to match it to your cup assembly and fixture.

Key Specs

  • Part Number: AVID-WLDSPC-SMC1
  • Component Type: Welding Slug
  • Inside Diameter: 12 mm nominal; 0.4724 in
  • Outside Diameter: 1.355"; 1.3550" ±0.0030" (34.42 ±0.08 mm)
  • Overall Length / Height: 2.25"; 2.2500" ±0.0030" (57.15 ±0.08 mm)
  • Material: 6061 Aluminum
  • Included: Single welding slug

Fitment Notes

Verify the cup assembly spacing, outside diameter, and through-bore before ordering or welding. Final fitment depends on your cup assembly, fixture, and mating hardware.
