ADS Direct Fit 2.5" Piggyback Race Shocks - Rear 250-C2535-R00

ADS Direct Fit 2.5" Piggyback Race Shocks - Rear 250-C2535-R00

The ADS Direct Fit 2.5" Piggyback Race Shocks - Rear 250-C2535-R00 is an ADS factory-replacement shock identified by manufacturer part number 250-C2535-R00. 2.5" 2019-'24 GM 2500 HD With Piggyback Reservoir (0.0 - 1.0 Lift).

What This Means on the Vehicle

• Product identity: The ADS part number is preserved as 250-C2535-R00.
• Application: 2019-2024 Chevrolet/ GMC 2500.

Vehicle Fitment

• 2019-2024 Chevrolet/ GMC 2500

Key Features

• Position: Front

Specifications

• Body Diameter: 2.5
• Collapsed Length: 16.04
• Extended Length: 26.06
• Hose Length: N/A
• Hose Outer Diameter: 0.875
• Mounting Hardware Included: Yes
• Lower Mount Type: Eyelet
• Reservoir Diameter: 2.5
• Reservoir Length: 8
• Shaft Material: Hard-chrome plated steel
• Shaft Diameter: 0.875
• Travel Length: 10.02
