Polaris RZR Pro R Outlaw Ti-Spec Series 64-Inch Titanium Front Control Arm Kit
Purchase Options
Select your vehicle to check compatibility. Contact AVID if you need help before ordering.
Contact AVID About FitmentFinal fulfillment timing is confirmed after checkout. Contact AVID before ordering if you have a firm deadline.
Product Details
Overview & Included Items
Polaris RZR Pro R Outlaw Ti-Spec Series 64-Inch Titanium Front Control Arm Kit
We built our Outlaw Ti-Spec Series 64-inch front control arm kit for Pro R drag racing, pairing Grade 9 titanium upper and lower control arms with lightweight modular knuckles, 7075-T6 aluminum rod ends, and a full titanium hardware kit.
This 64-inch kit narrows the front suspension 5 inches per side from factory. It converts the front suspension to an 8-inch air shock mounted on the front upper control arm (UCA), eliminating the factory front shock.
Our Grade 9 titanium control arms use titanium pivot crush sleeves and titanium mounting hardware. We include the uniballs, misalignments, bushings, and billet brake line clamps with the kit.
Construction and Fit
- 64-inch configuration, narrowed 5 inches per side from factory.
- 8-inch air shock conversion with the shock mounted on the front upper control arm.
- Eliminates the factory front shock.
- Titanium upper and lower front control arms in our Outlaw Ti-Spec Series.
- Lightweight modular knuckles and 7075-T6 aluminum rod ends.
- Titanium pivot crush sleeves and mounting hardware.
- Fits all Polaris RZR Pro R model years and configurations, including two-seat and four-seat models.
- For drag racing only. Not for other uses.
What's Included
- Titanium upper and lower front control arms.
- Lightweight modular knuckles.
- 7075-T6 aluminum rod ends.
- Uniballs, misalignments, and bushings.
- Titanium pivot crush sleeves and full titanium hardware kit.
- Tie rod adapter pin for a 3/4-inch tie rod end bearing.
- Billet brake line clamps.
Applications & Fitment
Applications With Conditions
-
Polaris RZR Pro R 2023
Troy Lee Designs Edition
- Position
- Front
- Requirements
- Included adapter pin fits a 3/4-inch tie rod end bearing. · 64-inch front kit, narrowed 5 inches per side from factory. · Uses an 8-inch air shock mounted on the front upper control arm (UCA), eliminating the factory front shock. · For drag racing only. Not for other uses.
-
Polaris RZR Pro R 2022
4 / Ultimate Launch Edition
- Position
- Front
- Requirements
- Included adapter pin fits a 3/4-inch tie rod end bearing. · 64-inch front kit, narrowed 5 inches per side from factory. · Uses an 8-inch air shock mounted on the front upper control arm (UCA), eliminating the factory front shock. · For drag racing only. Not for other uses.
-
Polaris RZR Pro R 2026
Ultra Edition
- Position
- Front
- Requirements
- Included adapter pin fits a 3/4-inch tie rod end bearing. · 64-inch front kit, narrowed 5 inches per side from factory. · Uses an 8-inch air shock mounted on the front upper control arm (UCA), eliminating the factory front shock. · For drag racing only. Not for other uses.
-
Polaris RZR Pro R 2022
Ultimate Launch Edition
- Position
- Front
- Requirements
- Included adapter pin fits a 3/4-inch tie rod end bearing. · 64-inch front kit, narrowed 5 inches per side from factory. · Uses an 8-inch air shock mounted on the front upper control arm (UCA), eliminating the factory front shock. · For drag racing only. Not for other uses.
-
Polaris RZR Pro R 2026
4 / Ultra Edition
- Position
- Front
- Requirements
- Included adapter pin fits a 3/4-inch tie rod end bearing. · 64-inch front kit, narrowed 5 inches per side from factory. · Uses an 8-inch air shock mounted on the front upper control arm (UCA), eliminating the factory front shock. · For drag racing only. Not for other uses.
-
Polaris RZR Pro R 2023
4 / Troy Lee Designs Edition
- Position
- Front
- Requirements
- Included adapter pin fits a 3/4-inch tie rod end bearing. · 64-inch front kit, narrowed 5 inches per side from factory. · Uses an 8-inch air shock mounted on the front upper control arm (UCA), eliminating the factory front shock. · For drag racing only. Not for other uses.
Specifications
- Riding use
- Drag Racing
- Main construction
- Titanium
- Position / component
- Front control arms
- Overall width
- 64"
Installation requirements: Requires Air Shocks
